18.5.22 USARTn_INPUT - USART Input Register

Offset
0x058
Reset
Access
Name
Bit Name
31:16 Reserved
15 CLKPRS
When set, the PRS channel selected as input to CLK.
14:12 Reserved
11:8 CLKPRSSEL
Select PRS channel as input to CLK.
Value
0
1
2
3
4
5
6
7
8
9
10
11
7 RXPRS
When set, the PRS channel selected as input to RX.
6:4 Reserved
3:0 RXPRSSEL
Select PRS channel as input to RX.
Value
silabs.com | Building a more connected world.
USART - Universal Synchronous Asynchronous Receiver/Transmitter
Reset Access Description
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0 RW PRS CLK Enable
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0x0 RW CLK PRS Channel Select
Mode Description
PRSCH0 PRS Channel 0 selected
PRSCH1 PRS Channel 1 selected
PRSCH2 PRS Channel 2 selected
PRSCH3 PRS Channel 3 selected
PRSCH4 PRS Channel 4 selected
PRSCH5 PRS Channel 5 selected
PRSCH6 PRS Channel 6 selected
PRSCH7 PRS Channel 7 selected
PRSCH8 PRS Channel 8 selected
PRSCH9 PRS Channel 9 selected
PRSCH10 PRS Channel 10 selected
PRSCH11 PRS Channel 11 selected
0 RW PRS RX Enable
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0x0 RW RX PRS Channel Select
Mode Description
Bit Position
Reference Manual
1.2 Conven-
1.2 Conven-
1.2 Conven-
Rev. 1.1 | 592
