19.5.10 LEUARTn_TXDATAX - Transmit Buffer Data Extended Register (Async Reg)

For more information about asynchronous registers see
Offset
0x024
Reset
Access
Name
Bit Name
31:16 Reserved
15 RXENAT
Set to enable reception after transmission.
Value
0
1
14 TXDISAT
Set to disable transmitter directly after transmission has competed.
Value
0
1
13 TXBREAK
Set to send data as a break. Recipient will see a framing error or a break condition depending on its configuration and the
value of TXDATA.
Value
0
1
12:9 Reserved
8:0 TXDATA
Use this register to write data to the LEUART. If the transmitter is enabled, a transfer will be initiated at the first opportunity.
silabs.com | Building a more connected world.
LEUART - Low Energy Universal Asynchronous Receiver/Transmitter
4.3 Access to Low Energy Peripherals (Asynchronous
Reset Access Description
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0 W Enable RX After Transmission
Description
The receiver is not enabled after the frame has been transmitted
The receiver is enabled (setting RXENS) after the frame has been
transmitted
0 W Disable TX After Transmission
Description
The transmitter is not disabled after the frame has been transmitted
The transmitter is disabled (clearing TXENS) after the frame has been
transmitted
0 W Transmit Data as Break
Description
The specified number of stop-bits are transmitted
Instead of the ordinary stop-bits, 0 is transmitted to generate a break. A
single stop-bit is generated after the break to allow the receiver to de-
tect the start of the next frame
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0x000 W TX Data
Bit Position
Reference Manual
Registers).
1.2 Conven-
1.2 Conven-
Rev. 1.1 | 637
