28.5.28 LESENSE_CHx_TIMING - Scan Configuration (Async Reg)

For more information about asynchronous registers see
Offset
0x240
Reset
Access
Name
Bit Name
31:24 Reserved
23:14 MEASUREDLY
Configure measure delay. Sensor measuring is delayed for MEASUREDLY EXCLK cycles.
13:6 SAMPLEDLY
Configure sample delay. Sampling will occur after SAMPLEDLY SAMPLECLK cycles.
5:0 EXTIME
Configure excitation time. Excitation will last EXTIME EXCLK cycles.
silabs.com | Building a more connected world.
4.3 Access to Low Energy Peripherals (Asynchronous
Reset Access Description
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0xXXX RW Set Measure Delay
0xXX RW Set Sample Delay
0xXX RW Set Excitation Time
LESENSE - Low Energy Sensor Interface
Bit Position
Reference Manual
Registers).
1.2 Conven-
Rev. 1.1 | 994
