28.5.5 LESENSE_BIASCTRL - Bias Control Register (Async Reg)

For more information about asynchronous registers see
Offset
0x010
Reset
Access
Name
Bit Name
31:2 Reserved
1:0 BIASMODE
This bitfield is used to configure how LESENSE interacts with the bias module
Value
0
1
2
28.5.6 LESENSE_EVALCTRL - LESENSE Evaluation Control (Async Reg)
For more information about asynchronous registers see
Offset
0x014
Reset
Access
Name
Bit Name
31:16 Reserved
15:0 WINSIZE
In sliding window mode, this bitfield configures the window size. In step detection mode, this bitfield is used to configure the
threshold for step detection
silabs.com | Building a more connected world.
4.3 Access to Low Energy Peripherals (Asynchronous
Reset Access Description
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0x0 RW Select Bias Mode
Mode Description
DONTTOUCH Bias module is controlled by the EMU and is not affected by LESENSE
DUTYCYCLE Bias module duty cycled between low power and high accuracy mode
HIGHACC Bias module always in high accuracy mode
4.3 Access to Low Energy Peripherals (Asynchronous
Reset Access Description
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0x0000 RW Sliding Window and Step Detection Size
LESENSE - Low Energy Sensor Interface
Bit Position
Bit Position
Reference Manual
Registers).
1.2 Conven-
Registers).
1.2 Conven-
Rev. 1.1 | 965
