Silicon Laboratories EFR32xG14 Wireless Gecko Reference Manual page 898

Bit Name
9:8 INPUT9NEGSEL
Selects negative channel
Value
0
1
2
3
7:6 INPUT6NEGSEL
Selects negative channel
Value
0
1
2
3
5:4 INPUT4NEGSEL
Selects negative channel
Value
0
1
2
3
3:2 INPUT2NEGSEL
Selects negative channel
Value
0
1
2
3
1:0 INPUT0NEGSEL
Selects negative channel
Value
silabs.com | Building a more connected world.
Reset Access Description
0x1 RW Negative Input Select Register for ADCn_INPUT9 in Differential
Scan Mode
Mode Description
INPUT8 Selects ADCn_INPUT8 as negative channel input
INPUT10 Selects ADCn_INPUT10 as negative channel input
INPUT12 Selects ADCn_INPUT12 as negative channel input
INPUT14 Selects ADCn_INPUT14 as negative channel input
0x3 RW Negative Input Select Register for ADCn_INPUT1 in Differential
Scan Mode
Mode Description
INPUT1 Selects ADCn_INPUT1 as negative channel input
INPUT3 Selects ADCn_INPUT3 as negative channel input
INPUT5 Selects ADCn_INPUT5 as negative channel input
INPUT7 Selects ADCn_INPUT7 as negative channel input
0x2 RW Negative Input Select Register for ADCn_INPUT4 in Differential
Scan Mode
Mode Description
INPUT1 Selects ADCn_INPUT1 as negative channel input
INPUT3 Selects ADCn_INPUT3 as negative channel input
INPUT5 Selects ADCn_INPUT5 as negative channel input
INPUT7 Selects ADCn_INPUT7 as negative channel input
0x1 RW Negative Input Select Register for ADCn_INPUT2 in Differential
Scan Mode
Mode Description
INPUT1 Selects ADCn_INPUT1 as negative channel input
INPUT3 Selects ADCn_INPUT3 as negative channel input
INPUT5 Selects ADCn_INPUT5 as negative channel input
INPUT7 Selects ADCn_INPUT7 as negative channel input
0x0 RW Negative Input Select Register for ADCn_INPUT0 in Differential
Scan Mode
Mode Description
Reference Manual
ADC - Analog to Digital Converter
Rev. 1.1 | 898
