31.6.6 CRYPTO_CSTATUS - Control Status Register

Offset
0x018
Reset
Access
Name
Bit Name
31:25 Reserved
24:20 SEQIP
Next sequence instruction when in halted sequence
19:18 Reserved
17 SEQSKIP
When in halted sequence, tells whether next instruction will be skipped
16 SEQPART
Shows whether currently in part A or B of a sequence
Value
0
1
15:11 Reserved
10:8 V1
Selectable operand for arithmetic operations
Value
0
1
2
3
4
5
6
7
7:3 Reserved
