Silicon Laboratories EFR32xG14 Wireless Gecko Reference Manual page 978

Bit Name
Value
0
1
2
11:10 IDLECONF5
This bitfield determines how the alternate excite pin is configured during the idle phase
Value
0
1
2
9:8 IDLECONF4
This bitfield determines how the alternate excite pin is configured during the idle phase
Value
0
1
2
7:6 IDLECONF3
This bitfield determines how the alternate excite pin is configured during the idle phase
Value
0
1
2
5:4 IDLECONF2
This bitfield determines how the alternate excite pin is configured during the idle phase
Value
0
1
2
3:2 IDLECONF1
This bitfield determines how the alternate excite pin is configured during the idle phase
Value
0
1
2
silabs.com | Building a more connected world.
Reset Access Description
Mode Description
DISABLE ALTEX6 output is disabled in idle phase
HIGH ALTEX6 output is high in idle phase
LOW ALTEX6 output is low in idle phase
0x0 RW ALTEX5 Idle Phase Configuration
Mode Description
DISABLE ALTEX5 output is disabled in idle phase
HIGH ALTEX5 output is high in idle phase
LOW ALTEX5 output is low in idle phase
0x0 RW ALTEX4 Idle Phase Configuration
Mode Description
DISABLE ALTEX4 output is disabled in idle phase
HIGH ALTEX4 output is high in idle phase
LOW ALTEX4 output is low in idle phase
0x0 RW ALTEX3 Idle Phase Configuration
Mode Description
DISABLE ALTEX3 output is disabled in idle phase
HIGH ALTEX3 output is high in idle phase
LOW ALTEX3 output is low in idle phase
0x0 RW ALTEX2 Idle Phase Configuration
Mode Description
DISABLE ALTEX2 output is disabled in idle phase
HIGH ALTEX2 output is high in idle phase
LOW ALTEX2 output is low in idle phase
0x0 RW ALTEX1 Idle Phase Configuration
Mode Description
DISABLE ALTEX1 output is disabled in idle phase
HIGH ALTEX1 output is high in idle phase
LOW ALTEX1 output is low in idle phase
LESENSE - Low Energy Sensor Interface
Reference Manual
Rev. 1.1 | 978
