31.6.16 CRYPTO_SEQ1 - Sequence Register 1

Offset
0x054
Reset
Access
Name
Bit Name
31:24 INSTR7
Sequence instruction. See INSTR in CRYPTO_CMD for a possible values.
23:16 INSTR6
Sequence instruction. See INSTR in CRYPTO_CMD for a possible values.
15:8 INSTR5
Sequence instruction. See INSTR in CRYPTO_CMD for a possible values.
7:0 INSTR4
Sequence instruction. See INSTR in CRYPTO_CMD for a possible values.
31.6.17 CRYPTO_SEQ2 - Sequence Register 2
Offset
0x058
Reset
Access
Name
Bit Name
31:24 INSTR11
Sequence instruction. See INSTR in CRYPTO_CMD for a possible values.
23:16 INSTR10
Sequence instruction. See INSTR in CRYPTO_CMD for a possible values.
15:8 INSTR9
Sequence instruction. See INSTR in CRYPTO_CMD for a possible values.
7:0 INSTR8
Sequence instruction. See INSTR in CRYPTO_CMD for a possible values.
silabs.com | Building a more connected world.
Reset Access Description
0x00 RW Sequence Instruction 7
0x00 RW Sequence Instruction 6
0x00 RW Sequence Instruction 5
0x00 RW Sequence Instruction 4
Reset Access Description
0x00 RW Sequence Instruction 11
0x00 RW Sequence Instruction 10
0x00 RW Sequence Instruction 9
0x00 RW Sequence Instruction 8
Bit Position
Bit Position
Reference Manual
CRYPTO - Crypto Accelerator
Rev. 1.1 | 1067
