11.5.10 CMU_CALCTRL - Calibration Control Register

Offset
0x050
Reset
Access
Name
Bit Name
31:28 Reserved
27:24 PRSDOWNSEL
Select PRS input for PRS based calibration. Only change when calibration circuit is off.
Value
0
1
2
3
4
5
6
7
8
9
10
11
23:20 Reserved
19:16 PRSUPSEL
Select PRS input for PRS based calibration. Only change when calibration circuit is off.
Value
0
1
2
3
4
silabs.com | Building a more connected world.
Reset Access Description
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0x0 RW PRS Select for PRS Input When Selected in DOWNSEL
Mode Description
PRSCH0 PRS Channel 0 selected as input
PRSCH1 PRS Channel 1 selected as input
PRSCH2 PRS Channel 2 selected as input
PRSCH3 PRS Channel 3 selected as input
PRSCH4 PRS Channel 4 selected as input
PRSCH5 PRS Channel 5 selected as input
PRSCH6 PRS Channel 6 selected as input
PRSCH7 PRS Channel 7 selected as input
PRSCH8 PRS Channel 8 selected as input
PRSCH9 PRS Channel 9 selected as input
PRSCH10 PRS Channel 10 selected as input
PRSCH11 PRS Channel 11 selected as input
To ensure compatibility with future devices, always write bits to 0. More information in
tions
0x0 RW PRS Select for PRS Input When Selected in UPSEL
Mode Description
PRSCH0 PRS Channel 0 selected as input
PRSCH1 PRS Channel 1 selected as input
PRSCH2 PRS Channel 2 selected as input
PRSCH3 PRS Channel 3 selected as input
PRSCH4 PRS Channel 4 selected as input
Bit Position
Reference Manual
CMU - Clock Management Unit
1.2 Conven-
1.2 Conven-
Rev. 1.1 | 324
