Ruijie Networks RG-S2600E Series Cli Reference Manual page 78

S2600E/P CLI Reference Guide
Configuration Commands
Usage
guidelines
Examples
Platform
description
5.1.3
Execute the traceroute command to show all gateways passed by the test
packets from the source address to the destination address.
The ping ipv6 command can be used in the ordinary user
mode and the privileged mode. In the ordinary mode, only
the basic functions of ping ipv6 are available. In the
privileged mode, in addition to the basic functions, the
extension functions of the ping ipv6 are also available. For
the ordinary functions of ping ipv6, five packets of 100Byte
in length are sent to the specified IP address within the
specified period (2s by default). If response is received, '!'
is displayed. If no response is received, '.' displayed, and
the statistics is displayed at the end. For the extension
functions of ping ipv6, the number, quantity and timeout
time of the packets to be sent can be specified, and the
statistics is also displayed in the end. To use the domain
name function, configure the domain name server firstly.
For the concrete configuration, refer to the DNS
Configuration section.
The example below shows the ordinary ping ipv6.
Ruijie# ping ipv6 2000::1
Sending 5, 100-byte ICMP Echoes to 2000::1, timeout is
2 seconds:
< press Ctrl+C to break >
!!!!!
Success rate is 100 percent (5/5), round-trip min/avg/max
= 1/2/10 ms
The example below shows the extension ping ipv6.
Ruijie# ping ipv6 2000::1 length 1500 ntimes 100
timeout 3 data ffff source 192.168.4.10:
Sending 100, 1500-byte ICMP Echoes to 2000::1, timeout
is 3 seconds
< press Ctrl+C to break >
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!
Success rate is 100 percent (100/100), round-trip
min/avg/max = 2/2/3 ms
-
traceroute
Chapter 5 Network Connectivity Test Tool
