RG-S7808C Series Switches
Quick Installation Guide V1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RG-S7808C Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ruijie Networks RG-S7808C Series

Summary of Contents for Ruijie Networks RG-S7808C Series

  • Page 1 RG-S7808C Series Switches Quick Installation Guide V1.1...
  • Page 2 This document is provided “as is”. The contents of this document are subject to change without any notice. Please obtain the latest information through the Ruijie Networks website. Ruijie Networks endeavors to ensure content accuracy and will not shoulder any responsibility for losses and damages caused due to content omissions, inaccuracies or errors.
  • Page 3 It is intended for the users who have some experience in installing and maintaining network hardware. At the same time, it is assumed that the users are already familiar with the related terms and concepts. Obtaining Technical Assistance  Ruijie Networks website: http://www.ruijienetworks.com/  Ruijie service portal: http://case.ruijienetworks.com Related Documents...

  • Page 4: Product Overview

    Launched by Ruijie independently, RG-S7808C series next generation core switches adopt the Crossbar architecture. RG-S7808C series switches support dual supervisor modules and power supply redundancy. Designed with eight horizontal slots, RG-S7808C series support dual supervisor modules and provides six slots for service modules. 2 Safety Precautions for Movement RG-S7808C series switches are large and heavy.

  • Page 5: Installation Site

    3.2 Installation Site RG-S7808C series must be used in the room. To ensure normal operation and a prolonged use life of the device, the installation site must meet the requirements of weight capacity, humidity , cleanness, EMI consideration, grounding system, power, and ventilation.

  • Page 6: Installation Tools

    · Figure 3-5 Cabinet Dimensions  Be sure that the slide rail in the cabinet is enough to bear the weight of a RG-S7808C and its installation accessories.  Be sure that the cabinet provides an earthing terminal for the switch to be grounded. ...

  • Page 7: Installing The Switch

    · 3.6 Unpacking Goods Checklist Device panels are installed and operational. Chassis Carton Fans, screwdriver, anti-static wrist strap, yellow/green grounding wires, quick installation guide, packing list Module Carton Modules, packing list, documentation A normal delivery should contain the above mentioned items, which may differ from the actual delivery, depending on purchase contracts.

  • Page 8: Installing Slide Rails

    · 4.2 Installing Slide Rails When installing slide rails for the RG-S7808C, ensure that the plane to carry the chassis should be installed on the plane of delimiters of 1 RU, as shown in Figure 4-2. Figure 4-2 Installing Slide Rails...

  • Page 9: Installing The Air Filter (Optional)

    · Note: ① and ② represents 1 RU delimiters. Before installing a slide rail, please verify that it is firm enough to bear the device weight and its installation accessories. There are variable kinds of slide rails. The rail appearance and installation is subject to actual conditions. In order to keep the cabinet balanced, please install the slide rail to as low a position as possible in the cabinet if only one RG-S7808C switch is installed.
  • Page 10 4.4 Installing External PoE Power Frame (Optional) The PoE power frame M78-PSE is an optional accessory. See RG-S7808C Series Switch Installation and Reference Guide for details. If the system is installed with a PoE-powered service module, e.g., M7800C-48GT4XS-P-EA, you should select the proper PoE power frame and PoE module.

  • Page 11: Mounting The Switch To A Cabinet

    Precautions Before mounting RG-S7808C series to the cabinet, first verify that the front and back brackets of the cabinet are at the right locations. If the bracket is too far forward, the front panel of the equipment may be too close to the front door, so that the front door cannot be closed when network cables and fibers are connected.
  • Page 12 · It is recommended to have three people carry or lift the switch. One is responsible for directing and the other two carrying or lifting the switch. Installation Steps Measure the cabinet height and locate the position on the bracket for installing the slide rail. Then locate the position on the other bracket through the carrying plane and mark the locations.

  • Page 13: Connecting The System Ground

    · 4.7 Connecting the System Ground A good grounding system protects your switch against lightning strikes and interferences and ensures its normal operation and reliability. Precautions  The sectional area of the grounding wire should be determined according to the possible maximum current. Cables of good conductor should be used.

  • Page 14: Installing Power Supplies

    (12AWG). 4.8 Installing Power Supplies The RG-S7808C series switches provide AC power supplies including RG-PA1600I-F and RG-PA600I-F, and PoE power supplies including RG-PA3000I-PLand RG-PA1600I-PL. Before performing the following procedures, wear an anti-static wrist trap close to your kin and keep it grounded.

  • Page 15: Installing Fans

    · The host power is the summation of the power of all working modules, including the supervisor module, service module and fan. For the power of each module, see RG-S7808C Series Switches Installation and Reference Guide. 4.9 Installing Fans Before the following procedures, wear an anti-static wrist trap close to your skin and have it properly grounded.
  • Page 16 · For the slot location of the supervisor module and service module, please see figure 4-12. Figure 4-12 Slot location ① Supervisor module slot ② Service module slot Note:  Install modules The supervisor module and service module adopt the design of self-locking lever. See figure 4-13 for operation. (1) Lever Operation Figure 4-13 Pulling out Lever (2) Module Installation...

  • Page 17: Connecting The Power Cord

    · If a slot is not inserted with a supervisor module, or service module, please cover the slot with a filler panel for heat dissipation. 4.11 Connecting the Power Cord Connect the power cord to the location as required according to the identification on the power module panel, including RG-PA1600I, RG-PA600I, RG-PA3000I-PL and RG-PA1600I-PL.

  • Page 18: Installation Verification

    Verify that the fan meets the requirement. See RG-S7808C Series Hardware Installation and Reference Guide for details.  Verify that the power supply is properly selected. See RG-S7808C Series Hardware Installation and Reference Guide for details.  Verify that the power module is inserted properly and the screws are fastened tightly.
  • Page 19 LEDs. Module LED Indicator Status Supervisor Module Status Solid green Service Module Status Solid green Power Supply Status Solid green Status Solid green For the detailed description of LEDs, see RG-S7808C Series Switches Hardware Installation and Reference Guide.
