Ruijie Networks RG-S2600E Series Cli Reference Manual page 883

S2600E CLI Reference Guide
access-list id {deny | permit} tcp [VID [out][inner in]]{source
source-wildcard | host Source | any} {host source-mac-address | any }
[operator port [port] ] {destination destination-wildcard | host destination |
any} {host destination-mac-address | any} [operator port [port] ]
[precedence precedence] [tos tos] [fragment] [range lower upper]
[time-range time-range-name] [match-all tcp-flag]
User Datagram Protocol (UDP)
access-list id {deny | permit} udp[VID [out][inner in]] {source source
–wildcard | host source | any} {host source-mac-address | any } [ operator
port [port] ] {destination destination-wildcard | host destination | any}{host
destination-mac-address | any} [operator port [port] ] [precedence
precedence] [tos tos] [fragment] [range lower upper] [time-range
time-range-name]
5. List remark
access-list id list-remark text
The following parameters are described in the sequence they appear. Once
described, a parameter will not be described anymore.
Parameter
description
Chapter 1 ACL Configuration Commands
Parameter
id
deny
permit
source
source-wildcard
protocol
Description
Access list ID. The ranges
available are 1 to 99, 100 to 199,
1300 to 1999, 2000 to 2699,
2700 to 2899, and 700 to 799.
If not matched, access
denied.
If matched, access is permitted.
Specify the source IP address
(host address or
address).
It can be discontinuous, for
example, 0.255.0.32.
IP protocol number. It can be
one of EIGRP, GRE, IPINIP,
IGMP, NOS, OSPF,
UDP, TCP, and IP. It can also
be a number representing the IP
protocol between 0 and 255.
The important protocols such as
ICMP, TCP, and UDP are
described separately.
is
network
ICMP,
