  • Page 1 RG-S2910XS-E Series Switch Hardware Installation and Reference Guide V1.14...

  • Page 2: Copyright Statement

    Ruijie Networks reserves all copyrights of this document. Any reproduction, excerption, backup, modification, transmission, translation or commercial use of this document or any portion of this document, in any form or by any means, without the prior written consent of Ruijie Networks is prohibited. Exemption Statement This document is provided “as is”.

  • Page 3: Obtaining Technical Assistance

    It is intended for the users who have some experience in installing and maintaining network hardware. At the same time, it is assumed that the users are already familiar with the related terms and concepts. Obtaining Technical Assistance  Ruijie Networks Website: https://www.ruijienetworks.com/  Technical Support Website: https://ruijienetworks.com/support...

  • Page 4: Product Overview

    Module Power Auto-sensing Port SFP Port Port Port Slot Slot Ethernet Port RG-S2910-24GT4XS-E RG-S2910-48GT4XS-E RG-S2910C-24GT2XS-P-E 24 (PoE+) 2 (Combo) RG-S2910C-24GT2XS-HP-E 24 (PoE+) 2 (Combo) Dual RG-S2910C-48GT2XS-HP-E 48 (PoE+) 2 (Combo) Dual The SFP+ ports support both 10Gbase-R and 1000base-X modules.

  • Page 5: Product Appearance

     HVDC input Voltage range: 192V to 290V Current range: 0.1A to 0.5A Earth Leakage ≤3.5mA Current Supported Not supported Power ≤24W Consumption Operating 0º C to 50º C (32º F to 122º F) Temperature Storage -40º C to 70º C (-40º F to 158º F) Temperature 10% to 90% RH Operating Humidity...

  • Page 6: Front Panel

    Front Panel Figure1-2 Front Panel of RG-S2910-24GT4XS-E Note 1. System status LED 4.10G SFP+ port 2. Console port 5.10G SFP+ port 3. 10/100/1000 Base-T auto-sensing Ethernet port 6. 10/100/1000 Base-T copper port status LED 7. SFP+ fiber port status LED Back Panel Figure 1-3 Back Panel of RG-S2910-24GT4XS-E...

  • Page 7: Power Supply

    Note 1. Grounding pole 3. Power cord retention clips 2. Three-hole AC power receptacle Power Supply The RG-S2910-24GT4XS-E switch adopts AC or HVDC power input.  AC input Rated voltage range: 100V to 240V, 50/60 Hz Maximum voltage range: 90V to 264V, 47 Hz to 63 Hz Frequency: 50/60 Hz Rated current: 1.5A Power cord specification: 10A...
  • Page 8 When installing the device, sufficient ventilation space (1 U (44.45 mm) distance from the adjacent device) should be reserved for the purpose of heat dissipation. LEDs Panel Marker Status Indication Blinking green The system is being initialized. Solid green The switch is operational. System status LED Status ...
  • Page 9 Current range: 0.5A to 0.8A Earth Leakage ≤3.5mA Current Supported Not supported Power ≤50W Consumption Operating 0º C to 50º C (32º F to 122º F) Temperature Storage -40º C to 70º C (-40º F to 158º F) Temperature 10% to 90% RH Operating Humidity Storage Humidity 5% to 95% RH...
  • Page 10 Front Panel Figure1-6 Front Panel of RG-S2910-48GT4XS-E Note 1. System status LED 4.10G SFP+ port 2. Console port 5.10G SFP+ port 3.10/100/1000 Base-T auto-sensing Ethernet port 6. 10/100/1000 Base-T copper port status LED 7. SFP+ port status LED Back Panel Figure 1-7 Back Panel of RG-S2910-48GT4XS-E...
  • Page 11 Note 1. Grounding pole 3. Power cord retention clips 2. Three-hole AC power receptacle Power Supply The RG-S2910-48GT4XS-E switch adopts AC or HVDC power input.  AC input Rated voltage range: 100V to 240V, 50/60Hz Maximum voltage range: 90V to 264V, 47 Hz to 63 Hz Frequency: 50/60 Hz Rated current: 1.5A Power cord specification: 10A...
  • Page 12 The port is not connected. Solid green The port is connected. SFP+ fiber port status LED 49F-52F Blinking Data are being transceived at the port. 1.3 RG-S2910C-24GT2XS-P-E Technical Specifications Model RG-S2910C-24GT2XS-P-E Single-core CPU with the clock speed of 1.0G BOOTROM Flash Memory...
  • Page 13 (W x D x H) Weight 5.8kg (with package) The RG-S2910C-24GT2XS-P-E switch is a class A product. In a domestic environment, this product may cause radio interference in which case the user may be required to take adequate measures. Product Appearance On the front panel, the RG-S2910C-24GT2XS-P-E Ethernet switch provides 24 10/100/1000Base-T Ethernet ports, 2 GE SFP fiber/copper combo ports, 2 10G SFP+ ports and 1 Console port.
  • Page 14 Figure 1-11 Back Panel of RG-S2910C-24GT2XS-P-E Note: 1. Grounding pole 2. Expansion module slot Power Supply The RG-S2910C-24GT2XS-P-E switch adopts AC or HVDC power input.  AC input Rated voltage range: 100V to 240V Maximum voltage range: 90V to 264V...
  • Page 15 Current range: 2.5A to 3.5A Heat Dissipation The RG-S2910C-24GT2XS-P-E adopts turbine fans for heat dissipation, thereby ensuring normal function of the device in the specified environment. 10 cm distance space should be reserved at both sides and the back plane of the cabinet to allow air circulation.
  • Page 16 Solid green The switch is operational. Temperature warning Solid yellow Check the working environment of the switch immediately. Solid red The switch is faulty. There is no expansion module or the expansion Expansion module module is not correctly installed. status LED Solid green The expansion module is correctly installed.
  • Page 17 Solid yellow The port is connected at 100 Mbps. Blinking yellow The port is connected at 100 Mbps. The port is not connected. Solid green The port is connected. SFP+ port status LED 25F-26F The port is receiving or transmitting traffic at 1000 Blinking green Mbps.
  • Page 18 Frequency range: 50/60 Hz Rated current: 10A 2) HVDC Voltage range: 192V to 290V Rated current: 10A  RG-M5000E-DC500P (DC) Voltage range: -72V to -36V Rated current: 16.5 A Earth Leakage ≤3.5mA Current Supported All the RJ45 ports are PoE-capable with the maximum power output of 30W. The available number of PDs is determined by PSE output power and PD input power in practice.
  • Page 19 Front Panel Figure 1-14 Front Panel of RG-S2910C-24GT2XS-HP-E Note Expansion module 1 status LED PoE mode switch-over button Expansion module 2 status LED Console port Power module 1 status LED 10. USB port Power module 2 status LED 11. 10/100/1000Base-T auto-sensing Ethernet port PoE status LED 12.
  • Page 20 Note: Expansion module 1 slot Power module 2 slot Expansion module 2 slot Grounding pole Power module 1 slot Power Supply The RG-S2910C-24GT2XS-HP-E supports 2 power modules with AC or DC input. For the detailed power specification, see the following tables. Model RG-M5000E-AC500P RG-M5000E-AC500P (HVDC)
  • Page 21 Protection 12V: 12A to 16A Over-Temperature Supported Protection Load-Balanced Power Supported Supply Supported with RG-M5000E-DC500P Power Supply Mix Power Cord Dimensions 224.5 mm x 90 mm x 40 mm (with connecting fingers and handles) (W x D x H) 195.4 mm x 90 mm x 40 mm (without connecting fingers or handles) Weight 1.6kg Model...
  • Page 22 Protection Load-Balanced Power Supported Supply Power Supply Mix Supported with RG-M5000E-AC500P Power Cord PD650I (DC) Dimensions 224.5 mm x 90 mm x 43.2 mm (with connecting fingers and handles) (W x D x H) 195.4 mm x 90 mm x 43.2 mm (without connecting fingers or handles) Weight 1.6kg RG-PA1150P-F...
  • Page 23 Over-Temperature Supported Protection Load-Balanced Power Supported Supply Power Supply Mix Not supported Power Chord Dimensions 301 mm x 90 mm x 40 mm (with connecting fingers and handles) (W x D x H) 281 mm x 90 mm x 40 mm (without connecting fingers or handles) 1.6kg Weight Dual-power input: The switch can be powered by one power module, or two power modules.
  • Page 24 LEDs Panel Identification State Meaning The switch is not receiving power. The system is being initialized. Blinking green Continuous blinking indicates errors. Solid green The switch is operational. System status LED Status Temperature warning Solid yellow Check the working environment of the switch immediately.
  • Page 25 Solid green The expansion module is correctly installed. The power module is not in place. Power module status The power module is in place but the AC power PWR1/PWR2 Solid red cord or switch is abnormal. Solid green The power supply is operational. Solid green Indicates the switching state.
  • Page 26 The port is not connected. Solid green The port is connected. SFP+ port status LED 25F-26F The port is receiving or transmitting traffic at 1000 Blinking green Mbps. 1.5 RG-S2910C-48GT2XS-HP-E Technical Specifications Model RG-S2910C-48GT2XS-HP-E Single-core CPU with the clock speed of 1.0G BOOTROM Flash Memory 512MB...
  • Page 27 Rated current: 10A HVDC Rated voltage range: 192V to 290V Rated current: 10A  M5000E-DC500P (DC) Rated voltage range: -72V to -36V Rated current:16.5A Earth Leakage ≤3.5mA Current Supported All the RJ45 ports are PoE-capable with the maximum power output of 30W. The available number of PDs is determined by PSE output power and PD input power in practice.
  • Page 28 Front Panel Figure 1-18 Front Panel of RG-S2910C-48GT2XS-HP-E Note: 1. System status LED 8. Fiber port status LED 2. Expansion module 1 status LED 9. PoE mode switch-over button 3. Expansion module 2 status LED 10. Console port 4. Power module 1 status LED 11.
  • Page 29 Figure 1-19 Back Panel of RG-S2910C-48GT2XS-HP-E Note: Expansion module 1 slot Power module 2 slot Expansion module 2 slot Grounding pole Power module 1 slot Power Supply The RG-S2910C-48GT2XS-HP-E supports two power modules with AC or DC input. For the detailed power specification, see the section of Power Supply for RG-S2910C-48GT2XS-HP-E.
  • Page 30 LEDs Panel Identification State Meaning The switch is not receiving power. The system is being initialized. Blinking green Continuous blinking indicates errors. Solid green The switch is operational. System status LED Status Temperature warning Solid yellow Check the working environment of the switch immediately.
  • Page 31 There is no expansion module or the expansion module is not correctly installed. Expansion module M1/M2 status LED Solid green The expansion module is correctly installed. The power module is not in place. Power module status The power module is in place but the AC power PWR1/PWR2 Solid red chord or switch is abnormal.
  • Page 32 The port is receiving or transmitting traffic at 100 Blinking yellow Mbps. The port is not connected. Solid green The port is connected SFP+ port status LED 49F-50F The port is receiving or transmitting traffic at 1000 Blinking green Mbps. 1.6 RG-S2910-24GT4XS-PS-E Technical Specifications Model...
  • Page 33 Warning EMCStandards GB9254-2008 Security Standards GB4943-2011 Dimensions 440mm x 200mm x 43.6mm (W x D x H) ≤ 3.5kg Weight The RG-S2910-24GT4XS-PS-E switch is a class A product. In a domestic environment, this product may cause radio interference in which case the user may be required to take adequate measures. Product Appearance On the front panel, the RG-S2910-24GT4XS-PS-E Ethernet switch provides 1 Console port, 24 10/100/1000Base-T Ethernet ports, 4 SFP+ ports and 1 Reset button.
  • Page 34 Note: 1. System status LED 5. Reset button 2. PowerShare status LED 6. Console port 3. 10/100/1000Base-T copper port status LED 7. 10/100/1000Base-T auto-sensing Ethernet port 4. SFP+ fiber port status LED 8. 10G SFP+ port Press the Reset button for less than 5s to collect system logs. Press the Reset button for 5s or more to collect system logs and then reboot the device.
  • Page 35 There are 0.5/3/10m power sharing cables for your choice. Use one power sharing cable to connect two S2910-24GT4XS-PS-E switches. If the local power supply of Switch A is disconnected but that of Switch B remains connected, Switch B provides 12V DC voltage to Switch A via the power sharing cable. In this way, Switch A is able to continue its operation.
  • Page 36 Temperature warning Solid yellow Check the working environment of the switch immediately. Solid red The switch is faulty. The switch is not receiving power. PowerShare status Solid green The switch is receiving local power supply. The switch is receiving PowerShare power Solid yellow supply.
  • Page 37 Model Description External Port M2910-01XT 1-port 10G copper module 1 10GBASE-T auto-sensing Ethernet port M2910-01XS 1-port SFP+ module 1 SFP+ port M2910-02XS 2-port SFP+ module 2 SFP+ ports For the detailed information about the supported modules, please refer to Switch Expansion module Usage Guide.

  • Page 38: Preparation Before Installation

    2 Preparation before Installation 2.1 Safety Suggestions To avoid personal injury and equipment damage, please carefully read the safety suggestions before you install the RG-S2910XS-E series switch. The following safety suggestions do not cover all possible dangers. 2.1.1 Installation  Keep the chassis clean and free from any dust.

  • Page 39: Static Discharge Damage Prevention

    If a power supply system is equipped with a leakage protector (also referred to as "leakage current switch" or "leakage current breaker"), the rated leakage action current of each leakage protector is greater than twice of the theoretical maximum leakage current of all the power supplies in the system. For example, if a system is equipped with sixteen identical power supplies, the leakage current of each power supply is equal to or less than 3.5mA, and the leakage current of the system totals 56mA.

  • Page 40: Installation Site Requirements

    2.2 Installation Site Requirements To ensure the normal working and a prolonged durable life of the equipment, the installation site must meet the following requirements. 2.2.1 Ventilation For the RG-2910XS-E, a sufficient space (at least 10 cm distances from both sides and the back plane of the cabinet) should be reserved at the ventilation openings to ensure the normal ventilation.

  • Page 41: Safety Grounding

    Table 2-2 Requirements for the Dust Content and Granularity in the Equipment Room Dust Unit Density Diameter≥0.5μm ≤3.5×10 Particles/m Diameter≥5μm ≤3×10 Particles/m Apart from dust, the salt, acid and sulfide in the air in the equipment room must also meet strict requirements, as such poisonous substances may accelerate the corrosion of the metal and the aging of some parts.

  • Page 42: Emc Grounding

    The lightning protection system of a facility is an independent system that consists of the lightning rod, download conductor and the connector to the grounding system, which usually shares the power reference ground and yellow/green safety cable ground. The lightning discharge ground is for the facility only, irrelevant to the equipment. EMC Grounding The grounding required for EMC design includes shielding ground, filter ground, noise and interference suppression, and level reference.

  • Page 43: Requirements Of Installation Tools

     The grounding device of the switch must not be used as the grounding device of the electrical equipment or anti-lightning grounding device. In addition, the grounding device of the switch must be deployed far away from the grounding device of the electrical equipment and anti-lightning grounding device. ...

  • Page 44: Product Installation

    3 Product Installation Please ensure that you have carefully read Chapter 2. Make sure that the requirements set forth in Chapter 2 have been met. 3.1 Installation Flowchart 3.2 Confirmations before Installation Before installation, please confirm the following points:  Whether ventilation requirements are met for the switch ...
  • Page 45  Connect the power cables of different colors to the corresponding grounding posts.  Ensure that the interface of the power supply cable is well connected to the power interface of the device. The power cables must be protected using power cable retention clips after they are connected to the device. ...

  • Page 46: Mounting The Switch On The Wall

    Use the supplied M6 screws and cage nuts to securely attach the mounting brackets to the rack, as shown in Figure 3-3. Figure 3-3 3.3.2 Mounting the Switch on the Wall The RG-2910XS-E series switch can be mounted on the wall, as shown in the following figure. Attach the mounting brackets to the switch with the supplied screws, as shown in Figure 3-4.

  • Page 47: Mounting The Switch On A Table

    Use the expansion screws to securely attach the mounting brackets on the wall, as shown in Figure 3-5. Figure 3-4 Attaching the Switch on the Wall 3.3.3 Mounting the Switch on a Table Attach the four rubber feet to the recessed areas on the bottom of the switch, as shown in Figure 3-6. Figure 3-6 Attaching the Rubber Feet to the Recessed Areas...
  • Page 48 Place the switch on the table, as shown in Figure 3-7. Figure 3-7 Mounting the Switch on the Table The device must be installed and operated in the place that can restrict its movement. 3.3.4 Connecting Power Sharing Cables The S2910-24GT4XS-PS-E switch supports power sharing among up to 3 devices. The cable-connecting steps are as follows.
  • Page 49 Step 3: If the power sharing combination is composed by two switches, you just need one power sharing cable. Respectively choose one port on both switches to connect the cable as illustrated in Step 2. Figure 3-9 Connecting Cables between Two Switches If the power sharing combination is composed by three switches, you need three power sharing cables.

  • Page 50: Checking After Installation

    Figure 3-12 Connecting Cables Among Three Switches 3 Step 4: Keep the Powershare ports covered by dust caps when these ports are not in use. 3.4 Checking after Installation Before checking the installation, switch off the power supply so as to avoid any personal injury or damage to the component due to connection errors.

  • Page 51: System Debugging

    4 System Debugging 4.1 Establishing the Debugging Environment Establishing the Debugging Environment Connect the PC to the console port of the switch through the console cable, as shown in Figure 4-1. Figure 4-1 Schematic Diagram of the Configuration Environment Connecting the Console Cable ...
  • Page 52 Enter the name of the new connection and click OK, the interface as shown in figure 4-3 is displayed. Choose the serial port used currently in the column [use when connecting]. Figure 4-3 After choosing the serial port, click OK to display the serial port parameter setting interface, set the baud rate to 9600, data bit to 8, parity check to none, stop bit to 1 and flow control to none.

  • Page 53: Startup Check

    After setting the parameters, click OK to enter the hyper terminal interface. 4.2 Startup Check 4.2.1 Checking before the Device is Powered on  The switch is fully grounded.  The power cable is correctly connected.  The power supply voltage complies with the requirement of the switch. ...
  • Page 54  Check whether the service interface forwards data normally.

  • Page 55: Maintenance And Troubleshooting

    5.2 Troubleshooting Common Faults Symptom Possible Causes Solution Forgetting the A password is manually configured but Please contact Ruijie Networks Customer Service management interface it is forgotten. Department for technical support. login password The status indicator is The power supply module does not...
  • Page 56 remove the unused power module. 2) The power module is faulty. Please replace a power module. The serial port connected to the switch The serial port Change the serial port opened by the configuration does not match that opened by the console has no output software to be the one connected to the switch.

  • Page 57: Appendix A Connectors And Connection Media

    6 Appendix A Connectors and Connection Media 1000BASE-T/100BASE-TX/10BASE-T Ports The 1000BASE-T/100BASE-TX/10BASE-T is a port that supports adaptation of three rates, and automatic MDI/MDIX Crossover at these three rates. The 1000BASE-T complies with IEEE 802.3ab, and uses the cable of 100-ohm Category-5 or Supper Category-5 UTP or STP, which can be up to 100 m.

  • Page 58: Optical Fiber Connection

    Optical Fiber Connection For the optical fiber ports, select single-mode or multiple-mode optical fibers for connection according to the fiber module connected. The connection schematic diagram is shown in Figure A-4: Figure A-4 Optical Fiber Connections...

  • Page 59: Appendix B Mini-Gbic And Spf+ Module

    7 Appendix B Mini-GBIC and SPF+ Module SFP module (Mini-GBIC module) and 10G SFP+ module are available to address the requirements of interface types of switch modules. You can select the Mini-GBIC or SFP+ module to suit your specific needs. Besides the following modules, the 10G SFP+ module also supports the Mini-GBIC-GT module.
  • Page 60 Table B-3 Specifications of SFP BIDI Optical Module Pairs Rate/Distance Module Pairs FE-SFP-LX20-SM1310-BIDI 100M/20km FE-SFP-LX20-SM1550-BIDI FE-SFP-LH40-SM1310-BIDI 100M /40km FE-SFP-LH40-SM1550-BIDI GE-SFP-LX20-SM1310-BIDI 1000M /20km GE-SFP-LX20-SM1550-BIDI GE-SFP-LH40-SM1310-BIDI 1000M /40km GE-SFP-LH40-SM1550-BIDI The BIDI modules must be used in pairs (e.g., FE-SFP-LX20-SM1310-BIDI and FE-SFP-LX20-SM1550-BIDI). Table B-4 Models and Technical Specifications of the Mini-GBIC-GT Module The existing SFP copper module: Standard 1000Base-T SFP Type...
  • Page 61 The existing 10G SFP+ copper modules: Copper Module Connector Conductor Wire Data Model Cable Type Type Diameter (AWG) Rate(Gb/s) (Yes/No) Length(m) XG-SFP-CU1M Passive SFP+ 10.3125 XG-SFP-CU3M Passive SFP+ 10.3125 XG-SFP-CU5M Passive SFP+ 10.3125 For the optical module with transmission distance exceeding 40 km and more, one on-line optical attenuator should be added on the link to avoid the overload of the optical receiver when short single-mode optical fibers are used.

  • Page 62: Appendix C Lightning Protection

    8 Appendix C Lightning Protection Installing AC Power Arrester (lightning protection cable row) The external lightning protection cable row shall be used on the AC power port to prevent the switch from being struck by lightning when the AC power cable is introduced from the outdoor and directly connected to the power port of the switch. The lightning protection cable row is fixed on the cabinet, operating table or the wall in the machine room using the line buttons and screws.
  • Page 63 During the switch usage, the Ethernet port arrester shall be connected to the switch to prevent the switch damage by lightning before the outdoor network cable connects to the switch. Tools: Cross or straight screwdriver, Multimeter, Diagonal pliers Installation Steps: Tear one side of the protection paper for the double-sided adhesive tape and paste the tape to the framework of the Ethernet port arrester.
  • Page 64  Reversed direction of the arrester installation. You shall connect the external network cable to the “IN” end and connect the switch Ethernet port to the “OUT” end.  Poor arrester grounding. The length of the grounding line should be as short as possible to ensure that it is in good contact with the switch grounding terminal.

  • Page 65: Appendix D Cabling Recommendations In Installation

    9 Appendix D Cabling Recommendations in Installation When RG-S2910XS-E series switches are installed in standard 19-inch cabinets, the cables are tied in the binding rack on the cabinet by the cabling rack, and top cabling or bottom cabling is adopted according to the actual situation in the equipment room.
  • Page 66  Cables of different types (such as power cords, signal cables, and grounding cables) should be separated in cabling and bundling. When they are close, crossover cabling can be adopted. In the case of parallel cabling, power cords and signal cables should maintain a space equal to or greater than 30 mm. ...
  • Page 67 Figure D-3 Bundling Up Cables (3)  Cables not to be assembled or remaining parts of cables should be folded and placed in a proper position of the cabinet or cabling slot. The proper position indicates a position that will not affect device running or cause device damage or cable damage during commissioning.
  • Page 68  The hard power cable should be fastened by the terminal connection area to prevent stress.  Do not use self-tapping screws to fasten terminals.  Power cables of the same type and in the same cabling direction should be bundled up into cable bunches, with cables in cable bunches clean and straight.

  • Page 69: Appendix E Site Selection

    10 Appendix E Site Selection  The machine room should be at least 5km away from the heavy pollution source such as the smelter, coal mine and thermal power plant, 3.7km away from the medium pollution source such as the chemical industry, rubber industry and electroplating industry, and 2km away from the light pollution source such as the food manufacturer and leather plant.
