4.7.34 VMONCAL1 - VMON Calibration Register 1

Offset
0x144
Access
Name
Bit Name
31:28 IO02V98THRESCOARSE
27:24 IO02V98THRESFINE
23:20 IO01V86THRESCOARSE
19:16 IO01V86THRESFINE
15:12 DVDD2V98THRESCOARSE
11:8 DVDD2V98THRESFINE
7:4 DVDD1V86THRESCOARSE
3:0 DVDD1V86THRESFINE
silabs.com | Building a more connected world.
Bit Position
Access Description
RO IO0 2.98 V Coarse Threshold Adjust
RO IO0 2.98 V Fine Threshold Adjust
RO IO0 1.86 V Coarse Threshold Adjust
RO IO0 1.86 V Fine Threshold Adjust
RO DVDD 2.98 V Coarse Threshold Adjust
RO DVDD 2.98 V Fine Threshold Adjust
RO DVDD 1.86 V Coarse Threshold Adjust
RO DVDD 1.86 V Fine Threshold Adjust
