(A) – Carrier
1 Driver's cab
2 Boom rests
3 Counterweight platform
4 Axle lines
5 Outrigger beams
6 Outrigger cylinders
7 Outrigger pads
(B) – Superstructure
8 Slewing gear
9 Crane cab
10 Main boom with telescoping mechanism
11 Telescopic sections
12 Hook block
13 Derricking cylinder, derricking gear
14 Telescoping cylinder
15 Turntable
16 Counterweight
17 Main hoist
18 Auxiliary hoist
1)
Additional equipment
