1 Slewing gear/movements locked display
2 Parking brake/movements locked display/warning
3 Suspension on/off display/warning
4 Pre-select front left outrigger display
4.1 Pre-select front left outrigger
5 Pre-select front right outrigger display
5.1 Pre-select front right outrigger
6 Pre-select rear left outrigger display
6.1 Pre-select rear left outrigger
7 Pre-select rear right outrigger display
7.1 Pre-select rear right outrigger
8 Current inclination display
9 Exiting the menu
10 Switching to the Outrigger cylinders menu
11 Outrigger control units on/off
12 Outrigger lighting on/off
