1 Display CCS
Overview start menu
2 Jog dial
3 Exiting the menu/input mode
4 Selecting / deselecting favourites
5 Warning for lifting limit switch shutdown
6 Sensor for brightness
7 Menu control
Select / activate / confirm
8 Display temperature warning display
9 Service/diagnosis connection
10 Overview menu groups – Operation
Overview menu groups – Overview
11 Switch off the RCL buzzer
12 Slewing gear brake engaged/released
13 Function only in the menu Outrigger
1
1)
For Service personnel only, not suitable for external devices, e.g. mobile
phone
