Operating manual
GMK4100L-1
Enter desired parameter
1 Input load
2 Input working radius
3 Input main boom length
4 Input slewing range
Pre-selection telescoping
5 Sort values
6 Selectable telescoping display
6.1 Associated maximum load
6.2 Associated maximum working radius
6.3 Associated telescoping duration
6.4 Associated main boom length
7 Overview of the table lengths
1)
Display only with the MAXbase slewing range type
1)
3 302 690 en
Operating elements for crane operation
9.1 Overview of the operating elements
à
à
à
à
à
à
à
à
à
à
p. 9 - 141
p. 9 - 141
p. 9 - 141
p. 9 - 141
p. 9 - 141
p. 9 - 141
p. 9 - 141
p. 9 - 141
p. 9 - 141
p. 9 - 141
s
9 - 43
