H
Operating manual
GMK4100L-1
1 Input access code emergency program
2 Remaining time emergency program display
3 Telescoping cylinder length displays
4 – Locking status telescoping cylinder display
– Locking/unlocking the telescoping cylinder
5 – Locking status telescopic section display
– Locking/unlocking a telescopic section
6 Display, position of the telescoping cylinder in the
foot section
Displays for the extended emergency operation
These displays are primarily intended for service personnel and are
therefore only mentioned in this operating manual and are not described
in more detail.
7 – Telescoping cylinder locked
– Telescopic section unlocked
8 – Telescoping cylinder locked
– Telescopic section locked
9 – Telescoping cylinder unlocked
– Telescopic section locked
10 Telescoping cylinder in the foot section
11 Left telescoping cylinder unlocked
12 Right telescoping cylinder unlocked
13 Telescoping cylinder just before the locking point
14 Telescoping cylinder just behind the locking point
The following applies to all displays
– Grey: Described position not reached
– Coloured: Described position reached
3 302 690 en
Operating elements for crane operation
9.1 Overview of the operating elements
à
à
à
à
à
à
p. 14 - 31
p. 14 - 31
p. 14 - 31
p. 14 - 31
p. 14 - 31
p. 14 - 31
s
9 - 61
