24
Steering with separate steering – manual
The symbol (3) is displayed.
•
Steer the 1st and 2nd axle lines with the button (1).
•
Steer the 3rd and 4th axle lines with the button (2).
– To turn to the left:
– To turn to the right:
The axle lines are steered as long as you keep the button pressed or until an
end position is reached.
3 302 710 en
•
Press buttons (1), (2) to the left.
•
Press buttons (1), (2) to the right.
(A) – For driving around corners
•
Steer the 3rd and 4th axle lines opposite to
the 1st and 2nd axle lines.
(B) – For crab travel mode
•
Steer the 3rd and 4th axle lines in the same
direction as the 1st and 2nd axle lines.
