Operating elements for crane operation
9.2 Short description of the operating elements
9.2.27
S
9.2.28
9 - 156

Diagnostics

The diagnostics connections may only be operated by the service personnel.
Risk of damage to the crane control system!
Do not connect external devices to the diagnostic connections.
This prevents severe malfunctions in the crane control system.

Other

Disclaimer menu
– To open: Select and confirm symbol (1). The warranty waiver text is
shown on the display.
The following connections are below the
.
cover (4)
1 CCS diagnostics –
(serial interface)
2 CCS diagnostics – CAN bus
3 RCL diagnostics
Additional diagnostic and service connections
are present on the CCS and RCL control
units (5).
•
Do not connect external devices, e.g. a
mobile phone, to these connections!
