Operating elements for crane operation
9.2 Short description of the operating elements
Windscreen
wiper/washing
system
9 - 148
Reading lamp
1 On
2 Off
Windscreen wiper on/off
– Off:
– Interval:
– Continuous operation:
Roof window wiper on/off
– Off:
– Interval:
– Continuous operation:
Windscreen washing system
– Windscreen: Push down
– Skylight: Push up
No additional wiping function is performed
Middle position
Push up – wiper goes to end position
Push down
Middle position
Push up – wiper goes to end position
Push down
