Manitowoc Grove GMK4100L-1 Operating Manual page 23

Crane's hydraulic
system Driving
mode
Closing menu
Additional pages GMK4100L-1
In driving mode, the crane's hydraulic system is driven by a different energy
source from the one used in crane operation.
The switchover is automatic, and the current status is displayed.
1 Arrow orange – crane's hydraulic system Driving mode on
The transmission mode RM, DM or neutral position N is selected –
you can carry out crane movements.
2 Arrow grey – crane's hydraulic system Driving mode off
The transmission mode D or R is selected – the crane movements are
disabled.
This section describes only how to close the Driving menu.
If you want to stop driving,
à
After driving , p. 30.
•
Apply the parking brake.
Press button (3) down once – lamp (2)
lights up.
•
Switch to crane operation mode.
Select symbol (1) and confirm – symbol is
white.
•
Close the Driving menu.
Press button (4) or (5) once.
3 302 710 en 19
