Operating manual
GMK4100L-1
Smallest individual width 1.170 m (3.8 ft)
This case applies when one outrigger beam is extended to a span
of 1.170 m (3.8 ft) and all other outrigger beams are extended to larger
spans.
Positional reference
1 To the right
2 Backwards
3 To the left
4 Forwards
Angular range
±85°
±5°
±85°
±5°
3 302 690 en
Crane operation
11.3 MAXbase slewing range type
Enabled slewing range
-175° to -5°
-5° to +5°
+5° to +175°
+175° to -175°
11 - 27
