Additional pages GMK4100L-1
1 Transmission mode RM
2 Transmission mode R
3 Neutral position N
4 Transmission mode D
5 Transmission mode DM
6 Current transmission mode display
7 Steering lock display
8 Current wheel position display
9 Change-over between crane operation and driving modes
10 – Transverse differential locks display
– Transverse differential locks on/off
11 – Longitudinal differential lock display
– Longitudinal differential lock on/off
12 Supply pressure brake circuits 1 and 2 display
13 Parking brake indicator lamp
14 Display of crane's hydraulic system driving mode on/off
15 Steering mode switched on indicator
16 Normal steering mode/on-road driving on
17 Separate steering, manual on
18 Automatic separate steering driving around corners on
19 Automatic separate steering for crab travel mode on
20 Changing the steering direction
1)
Display depends on carrier display;
1)
à
3 302 710 en
p. 5
à
p. 8
à
p. 7
à
p. 7
à
p. 7
à
p. 8
à
p. 6
à
p. 11
à
p. 6
à
p. 9
à
p. 9
à
p. 9
à
p. 9
à
p. 10
à
p. 10
à
p. 6
à
p. 13
à
p. 12
à
p. 13
à
p. 13
à
p. 12
3
