1 Applying/releasing the parking brake
2 – Starting the engine
– Set idling speed
3 RCL override – Version A
– Overriding the RCL
RCL override – Version B
– Overriding the RCL in an emergency
4 Headlight on/off
5 Slewable spotlights on/off
6 Slew slewable spotlight
7 RCL override – Version A
– Raise enable button after RCL shutdown
RCL override – Version B
– No function
8 Windscreen wiper on/off
9 Roof window wiper on/off
10 Windscreen washing system
1)
Additional equipment
2)
Version A or version B active depending on RCL programming
2)
2)
1)
1)
2)
2)
