Avaya DEFINITY Server CSI Maintenance Manual page 77

Troubleshooting Features
Time Slot Test Call
The time slot test call connects the voice terminal user to a specific time slot
located on the TDM Buses (A or B) or out-of-service time slots. Specific Time
Slots To place the call:
1. Dial the Facility Test Call Feature Access Code and listen for dial tone.
The Feature Access Code is set on the Feature Access Codes screen.
2. Dial port network number (1), then press
"sixty," where:
xxx
3. Listen for one of the following tones:
555-233-119
= Time slot number (000 through 255 on Bus A and 256
through 511 on Bus B)
Confirmation Tone—time slot is idle or maintenance busy
Reorder Tone—time slot is busy
Dedicated Tone—One of the following tones is heard (see
on page 77).
Table 5. TDM Bus Time Slot Numbers
TDM Bus A TDM Bus B
time slot
000
001
002
003
004
005
006
007
008
009
010
011
012
013
014
and the 3-digit time slot number
#
time slot
256 Reorder
257 Reorder
258 Reorder
259 Reorder
260 Reorder
261 Touch Tone 1 - 697Hz
262 Touch Tone 2 - 770 Hz
263 Touch Tone 3 - 852Hz
264 Touch Tone 4 - 941 Hz
265 Touch Tone 5 - 1209 Hz
266 Touch Tone 6 - 1336Hz
267 Touch Tone 7 - 1447 Hz
268 Touch Tone 8 - 1633 Hz
269 Dial Tone
270 Reorder Tone
Continued on next page
Issue 5 October 2002
Table 5
Tone Heard
77
