Avaya DEFINITY Server CSI Maintenance Manual page 128

Maintenance for CSI systems
Table 15.
TN230X LED reference
LED color
Red Green
- -
N/S Fast blink
- Slow blink
- Steady on
Steady on -
Table 16 shows the various LEDs on the A500 ATM switch and the meanings of
the different states.
Table 16. A500 LED Quick Reference
Component Label
Switch LK
Processor
Board
RX
DIAG
NBOOT
MGT
RUN
PWR
VOLT
TEMP
FAN
128
Issue 5 October 2002
— Continued
Yellow
100ms on / Loss of signal on the OC-3 fiber. Either the
100ms off TN230X-receive (top) or TN230X-transmit (bottom)
fibers are not working.
- Running DSP diagnostics or downloading code to DSPs
(typical during boot process).
- Board insertion has not yet completed.
- Running maintenance tests. May appear to be blinking if
several short tests are run one after another.
- Hardware alarm. Does not necessarily take the TN230X
out of service, for example, if one of the 24 DSPs fails
diagnostics.
Color State
Green Intermittent
blink
Green Steady on
Green Off
Green Off
Green Off
Green Steady on
Green Steady on
Yellow Off
Yellow Off
Yellow Off
Interpretation
Continued on next page
Meaning
Normal state. Traffic is being sent or received
over the Ethernet LAN link.
Normal state. Carrier is received over the
Ethernet LAN link.
Normal state.
Normal state.
Normal state.
Normal state. The switch processor is
running.
Normal state. The switch processor board is
powered up.
Normal state
Normal state
Normal state
Continued on next page
555-233-119
