Maintenance for CSI systems
7. Find the DID-TRK MO in the Maintenance Object chapter of the
appropriate maintenance book.
8. In the first table, look up the command to run in the MAJOR row of the
table.
In our example, Step
MAJOR alarm.
MO Name (in
Alarm Log) Alarm Level
DID-TRK MAJOR
DID-TRK MINOR
DID-TRK WARNING
1. UU is the universal cabinet number (1 for PPN, 2 - 44 for EPNs), C is the carrier designation (A, B,
C, D, or E), SS is the number of the slot in which the circuit pack resides (01 to 21), and pp is the
two digit port number (01, 02, ...).
2. A MAJOR alarm on a truk indicates that alarms on these trunks are downgraded by the set options
command and that at least 75% of the trunks in this trunk group are alarmed.
9. Type test port 01C1008 long and press
In our example, 01C1008 is the address of the alarmed port (see
on page 33
10. While the port test is running, look up the Error Type in the appropriate
Error Log Entries table.
In our example the Error type is 1537.
Table 2. DID Trunk Error Log entries
Error Aux
Type Data
1537 Port Diagnostic
(#35)
3840 (k) 40965 None
11. Since the Test to Clear Value (
test you ran in Step 9, wait for the results of the port test.
When the port test finishes, a Test Results screen appears
page
34
Issue 5 October 2002
4 indicated that a DID trunk in slot 10, carrier C has a
Initial Command to Run
2
test port UUCSSpp long
test port UUCSSpp long
test port UUCSSpp
and Screen 3 on page
Alarm
Associated Test Level
MAJ/MIN/
WRN
35).
1
DID Trunk
DID Trunk
DID Trunk
.
Enter
33).
On/Off
Board Test to Clear Value
OFF test port UUCSSpp sh r 1
Continued on next page
test port 01C1008 sh r 1) is similar to the initial
Full Name of MO
Screen 2
(Screen 4 on
