Avaya DEFINITY Server CSI Maintenance Manual page 111

LED Interpretation
cdr2-alrm
pr-sys-alm
pms-alarm
TN2402/TN798 Processor Circuit Pack LEDs
The front panels of the Processor circuit pack and the Maintenance circuit pack
are identical. Each has two groups of LEDs. One group indicates the status of the
pack, and the other group (which includes the Major, Minor, and Warning alarms
described in the
conditions in the entire system. See
Red (alarm)
Green (test)
Yellow (busy)
MAJOR ALARMS (red)
MINOR ALARMS (red)
EMERGENCY TRANSFER (red)
invoked
555-233-119
Call Detail Recording Alarm: The Secondary Link has a
Major, Minor, or Warning alarm active.
System Printer Alarm: The System Printer (SYS-PRNT) has
a Major, Minor, or Warning alarm active.
The Property Management System has a Major, Minor or
Warning alarm active.
''Alarm and Error Reporting''
—
the system has detected a fault in this circuit pack.
NOTE:
Alarms on the PROCR, PR-MAINT, MEMORY, and PR-MEM MOs
are indicated by the red LED on the Processor circuit pack.
—
the system is running tests on this circuit pack.
—
this circuit pack is in use.
NOTE:
If the AC power cord is unplugged, the emergency transfer feature
invokes, however the EMERGENCY TRANSFER LED (red) is not lit
due to loss of AC power.
section) reflects maintenance
Figure 14 on page 112.
—
indicates emergency transfer has been
Issue 5 October 2002
111
