Maintenance for CSI systems
A500 Administration
To check the administration of the A500:
1. Enter show signaling summary on the A500 console.
Screen 26
A500:show signaling summary
Port loc VCI
------ -------
A1.1 1
A1.2 2
Screen 26. Screen output for the show signaling summary command
If an A500 port attached to an Avaya Definity Server CSI port network is
not listed on this screen, use the admin link command to see if the port
was administered as having no UNI signaling.
Ensure that fields listed have the values indicated below.
If the A500 was administered using hard-coded PNNI routes to identify
each endpoint, enter show signaling routes on the A500 console.
Screen 27 on page 135
134
Issue 5 October 2002
shows the screen output.
SAP IntType Signaling
--- ------- -----------
1 Network UNI3.1
2 Network UNI3.1
Field
IntType Network
If User, links will not come up between the PPN and the
EPN.
Signaling UNI3.1
If UNI3.0, links will not come up between the PPN and
the EPN.
Preferred value is No, but this does not prevent links
ILMI
from coming up between the PPN and an EPN.
May or may not be UP. The value depends on more than
SAP State
whether the port was marked as UP. (See highlighted
data for SAP State in
shows the screen output from the command.
ILMI SAP State State
---- ------------ -----
No UP UP
No UP UP
Value
Screen 26 on page 134.)
