Control
Tap this button to control infusions using the Vevo Infusion Pump through the Vevo F2
Imaging System software. This button is available in acquisition and review and is
available for all m odes.
Infusion Pump
Once the Infusion Pump button is tapped, a flyout will be displayed. Tap Start Infusion
or tap and hold Quick Infuse to start an injection. Tap Stop Infusion or tap and hold
Quick Withdraw to stop an injection. Tap Infusion Settings to select the settings for
the Preset, Syringe and Infusion.
See Vevo Infusion Pump f or more details.
Allows you to enter a name for an image.
Name Image
Using the Name Image button will trigger a save of either a clip or frame. Select either
Save Clip or Save Frame on the Save tab in Clip Settings for the On "Name Image"
option.
New Series
Closes the current series and opens a new one. If you are scanning, this is quicker than
going into the Study Browser.
If you have selected a preset while scanning and have changed some of the scanning
Reset Preset
parameters, tapping this control will reset the parameters back to preset values.
Reset TGC
Resets the positions of all TGC sliders on the control panel to their default position.
Save
Tap this control to save the current configuration in all modes into a new application for
Application
the current transducer. See Applications & Presets on page 365.
Save Frame
Tap this control to save a single frame in frame-based modes (such as B-Mode).
Session Tasks
Note: The Reset Preset control is disabled during review.
Note: The Save Application control is disabled during review.
