Button
Start Recording
When the system saves the image, it will also provide an audible saving tone. When tapping Save Frame or
Save Clip, only one audible saving tone is heard. When tapping Start Recording, one audible saving tone
is heard when the save begins and another when the save is complete. For more information, refer to
System Sounds.
To review saved images for the current series, tap Current Series. For closed series, y ou must access the
images from the Study Browser.
Storage Space Indicator
The space available icon, located in the system status area at the bottom of the image display shows the
percentage of space available in internal storage.
If you try to save an image when space is low, the system alerts you that internal storage is low and prompts
you to delete data from the system.
Saving Frames or Clips
An image can be saved during live scanning or from an acquired image by tapping Save Frame or Save
Clip. The Save Clip control is permanently docked in the lower right corner of the control panel.
If the Save Frame button is not available, you can configure the system to display it. Tap More Controls
and then tap the General tab. See Customizing the Control Panel on page 91.
You can also save a frame-based image (such as B-Mode) by tapping Start Recording. If the Start
Recording button is not available, it can also be found on the General tab in More Controls.
To Save an Image While Scanning
Select one of the following options:
Session Tasks
Recording: Displayed during the acquisition.
Clip Stored: Displayed when save is complete.
Note: Available for frame-based modes.
Vevo F2 Imaging System User Manual
Message
99
