System Overview

Vevo F2 Imaging System
The Vevo F2 Imaging System consists of the following major components:
The top screen is the image display, which displays imaging data.
l
The bottom screen is the touchscreen control panel, which serves as the control surface for the
l
system.
The base of the system houses the electronics that make up the Vevo F2 Imaging System.
l
For more information about the system and its components, refer to Components on page 401.
Image Display
The image display is the top monitor of the Vevo F2, and primarily displays imaging data.
