With these settings, the Tx/Rx Event will start at element 1, then increment by 10 with each repetition (1, 11,
21, etc.) until it reaches element 91 (because the next element would be 101, which exceeds the stop
value).
Wait for Trigger In
A Wait for Trigger In block causes the system to wait for an external trigger signal into the Trig In BNC port
before running the next event in the pulse sequence.
When the trigger signal is received from the Trig In BNC port, the system will wait for the delay period set in
this block (if set) before running the next event in the pulse sequence.
Note: This block only affects the next transducer event in the pulse sequence.
Subsequent transducer events in the sequence are not affected. This differs from
the Trigger Out: On block, which affects every transducer event in the sequence
that is placed after the block.
Interface
When a Wait for Trigger In is selected, the following interface appears:
The Pulse Sequences menu when a Wait for Trigger In block is selected
The Wait for Trigger In block has two settings:
Modes
