Note: The PA Guide is an overlay only, and is not saved with your image. It will
not appear for images that are paused, opened for review, or opened after an
export.
To Use the PA Guide
The Guide Area of the PA Guide is automatically activated when you select PA-Mode, but the Guide Line
can be activated manually.
To use the PA Guide:
1. Select PA-Mode.
The PA-Mode interface appears. The Guide Area of the PA Guide appears automatically
2. To turn on the Guide Line part of the PA Guide, tap PA Guide and then select Guide Line. Note that
the Guide Line only appears on the image display.
3. Position the skin line of the animal within the Guide Area.
4. Continue with PA-Mode image acquisition.
For more information about PA-Mode image acquisition, refer to PA-Mode Image Acquisition
Workflow on page 165.
