3. Interact with the measurement using the control panel.
When placing a measurement, a magnified view of the placement area is displayed on the image
display.
To change the magnification, tap Magnify Scale and then use the Increase or Decrease buttons.
A measurement label is displayed next to the measurement on the image. It contains the
measurement's label, number, and value.
Note:
Changing the zoom value does not affect the measurement value,
parameters, or font size.
To Use the Measurements Panel
Once a measurement is added, a Measurements panel appears on the left side of the control panel.
Use this panel to select and edit measurements.
To expand or collapse the Measurements panel, tap the down or up arrows.
Session Tasks
The zoom scale factor can be changed while placing measurement.
