Create a Custom PA Spectral Curves
1. Acquire or load a PA-Mode (Spectro) image into review.
2. Place a PA Region measurement.
3. From the Measurement panel, select graph option for the PA Region measurement.
The PA Region Analysis window appears.
4. In the PA Region Analysis window, make any edits to the display options and PA regions as needed.
5. In the PA Regions window, tap Save Spectral Curves.
The Save Spectral Curves panel appears.
6. In the Save Spectral Curves panel, verify that all settings are correct and then tap Save.
The Spectral Curve will now be available in the PA Spectral Curves list on the Photoacoustics page in the
System Settings menu. It will also be available within the Unmixing and Multi-wavelength panels.
Sound & Display
Use the Sound & Display tab to adjust the volume of system sounds, or adjust the screen brightness.
To Display the Sound & Display Page
1. Tap More, and then tap System Settings.
2. Tap the Sound & Displaytab.
