Control Live/Review
Save Preset
Speed of
Sound
Transducer
Settings
Both
Transmit
Delays
Voltage
Waveforms
VADA Clip Settings
To access VADA clip settings, tap the Clip Settings control and navigate to the VADA tab.
Modes
Saves all currently selected settings into a preset. Saved presets are
accessed through the Presets control.
Live
For more information, refer to Applications & Presets on page 365.
Sets the speed of sound. Used to set a speed of sound that
corresponds to the medium used (such as gel or water).
To set the speed of sound, tap this button, then tap either the Speed
of Sound adjustment buttons or Configure to open the Speed
Live
of Sound menu.
The button shows the currently set speed of sound.
For more information, refer to Speed of Sound on page 245.
Opens the Transducer Settings menu. This menu displays the
properties of the currently selected transducer.
Opens the Transmit Delays tab of the VADA configuration panel.
Live
For more information, refer to Transmit Delays on page 259.
Opens the Voltage flyout menu, which allows you to select the
voltage used by the transducer.
Live
Voltages are selected as a percentage of the two voltage rails.
For more information, refer to Voltage on page 249.
Opens the Waveforms tab of the VADA configuration panel.
Live
For more information, refer to Waveforms on page 264.
Vevo F2 Imaging System User Manual
Description
243
