Session Tasks

An imaging session involves either scanning and acquiring a new image, or reviewing an image saved from
a previous imaging session.
A typical imaging session consists of the following steps:
1. Turn on the Vevo F2 (refer to System Startup on page 23).
2. Log into the Vevo F2 (refer to Logging In below).
3. Acquire an image, or open a previously saved image.
To acquire an image, select a transducer and an imaging mode (from the Modes on
o
page 108), then position the transducer on the animal.
To open a previously saved image, refer to Working with Images on page 332.
o
4. Navigate the interface, using the controls to switch viewing modes and adjust the image as
necessary. For more information, refer to:
Image Display on page 36
o
Control Panel Interface (Scanning) on page 38
o
Control Panel Interface (Review) on page 41
o
5. Add markup to the image, such as:
Annotations on page 56
o
Measurements on page 61
o
6. Save the image (refer to Saving Frames or Clips on page 99).
7. Log out (refer to Logging Out on page 107).
Note: This section assumes that the Vevo F2 Imaging System, Vevo LAZR-X
laser cart (if required), all required accessories, and all specimens are ready for
the imaging session. For information about setup, refer to Setup and
Maintenance.

Logging In

Once the Vevo F2 is on, the system software starts and the control panel displays the login page:
