4. Position the skin line of the animal within the Guide Area.
5. Adjust the PA-Mode box to the desired size and position.
To move the box, tap and drag it on the control panel.
o
To resize the box, tap and drag one of the circular handles located at the bottom-left and
o
bottom-right corners of the box.
6. Select a PA sub-mode.
Note: For a list of PA sub-modes, refer to List of PA Sub-Modes on
page 168.
7. Adjust any mode-specific settings as necessary.
Note:
PA Sub-Mode Settings on page 168.
8. Set desired PA-Mode scan parameters (such as frame delay, persistence, and respiration gating).
9. (Optional) Load or save a new PA-Mode preset.
10. Tap Start.
Modes
Note: By default, if the B-Mode image dimensions are changed, the
PA-Mode box will maximize to fit the entire image. Making the PA-
Mode box smaller will disable this feature. Manually maximizing the
PA-Mode box will re-enable this feature.
For a list of settings that appear after selecting a sub-mode, refer to
