Study Browser
When you acquire and save an image, the image can then be retrieved from the Study Browser at any time.
Each saved image consists of a collection of saved frames (either a set of selected frames, a single frame,
or all frames recorded during a time period).
You can also use the Study Browser to organize saved images in a hierarchy of studies and series:
1. Study: The highest level of organization. Used to group series.
2. Series: Used to group images.
3. Images: Individual collections of saved frames.
Filtering the List of Studies in the Study Browser
An icon is shown next to each study in the Study Browser list which shows if the study is private, shared with
the group, or shared with everyone.
To filter the list of studies in the Study Browser:
1. Tap the privacy icon in the upper left corner of the Study Browser.
2. A list appears with three options.
Study Browser
The study browser interface
