Once added, the waveform appears in the list of waveforms.
This numbered list shows the waveforms selected, in the order in which they will be used in the loop. In the
above example, the pulse sequence will use the "Negative - 1 Cycle" waveform on the first pass of the loop,
and the "Positive - 1 Cycle" waveform on the second pass before exiting the loop.
Repeat the above steps until all desired waveforms are added.
Delete a Waveform
1. Select a waveform.
2. Tap the Delete button (
Rearrange Waveforms
1. Select a waveform.
2. Tap the Up (
Modes
Waveforms menu, with multiple waveforms entered
).
) or Down (
) buttons to move the waveform up or down in the list.
Vevo F2 Imaging System User Manual
297
