6. Insert the optical fiber bundle ferrule into a port on the laser. Push the ferrule into the port until it
cannot go in any further.
Optical fiber bundle ferrule that is not
pushed all the way into the port. Note
the gap.
Caution:
from the laser, grasp the fiber optic cable by the ferrule. Do not push or pull
the ferrule by the cable.
7. Lock the optical fiber bundle ferrule by lowering the lever lock.
Components
Optical fiber bundle ferrule that is
correctly pushed all the way into the
When connecting or disconnecting the optical fiber bundle ferrule
Vevo F2 Imaging System User Manual
port.
