Indicator
LASER READY Indicates the laser is ready to generate a flashlamp output.
COOLANT FLOW Indicates the cooling system is on.
Indicates the back external interlock is satisfied. This indicator turns off when the
back interlock is disconnected.
EXT INTERLOCK
HEAD CABLE
Indicates the laser head cable interlock is engaged.
INTERLOCK
COVER
Indicates the optics cover interlock is engaged.
INTERLOCK
POWER ON Indicates the laser is powered on.
GENERAL Indicates a laser fault has occurred. Refer to Contact and Legal Information on
FAULT page 477 and call Technical Support.
HEAD TEMP Indicates the laser head temperature exceeds maximum limits (approximately
FAULT +70°C/158°F).
Indicates the DI filter needs to be replaced. Refer to Contact and Legal Information
on page 477 and call Technical Support.
COOLANT
RESISTANCE
COOLANT OVER Indicates the coolant in the cooling system reservoir exceeds minimum
TEMP temperatures.
COOLANT Indicates the volume of coolant in the cooling system reservoir is below minimum
LEVEL LOW levels.
HVPS FAULT Indicates an error in the high voltage power supply.
END OF Indicates the laser pulse forming network (PFN) has not charged to the programmed
CHARGE FAULT energy level.
Components
Description
Note: This only refers to the 15-pin port on the back of the
system.
Note: If the laser has not been used for some time, this light
may turn on for a few minutes, and then turn back off. If this
occurs, the DI filter does not need to be replaced.
