FujiFilm VisualSonics Vevo F2 User Manual page 292

This numbered list shows transmit delays in the order in which they will be looped. In the above example,
the pulse sequence will use the 10 mm profile on the first pass of the loop, the 20 mm profile on the second
pass, and the 30 mm profile on the third pass before exiting the loop.
Repeat the above steps until all desired transmit delay profiles are added.
Delete a Transmit Delay Profile
1. Select a transmit delay profile.
2. Tap the Delete button (
Rearrange Transmit Delay Profiles
1. Select a transmit delay profile.
2. Tap the Up (
Modes
Transmit delay menu with three transmit delays entered
).
) or Down ( ) buttons to move the profile up or down in the list.
Vevo F2 Imaging System User Manual
292
