Using the Measurements Panel
The Measurements panel provides tools for editing measurements on an image and options to change
which measurement properties are displayed.
The Measurements panel is only displayed once the first measurement is placed on an acquired or saved
image. The panel is not available during image acquisition.
Note: You must pause a clip before you can place a new measurement or interact
with previously saved measurements.
Common Tasks
To View Available Generic Measurements for an Image
1. Load/acquire an image into review by doing one of the following:
If you are in the Study Browser open a saved image. If the image is a clip, then pause the clip
o
at the frame you want to work with.
If you are acquiring image data, tap Freeze on the control panel.
o
Select an image from the Current Series option from the top menu.
o
2. View the available measurements by tapping the M easurements button. Only the available
measurements for the active mode will be available.
To Place a Measurement on an Image
1. Tap Measurements.
2. Tap a measurement from the list. The measurement is placed on the image.
Session Tasks
