FujiFilm VisualSonics Vevo F2 User Manual page 338

Before you begin, ensure that the Vevo F2 Imaging System is connected to a data storage location on your
network, or to an e xternal storage device through the appropriate ports o n the system.
To Export Images From the Mode Window
1. From the Mode window, tap Export.
2. The Export page appears. Browse to or manually enter the destination folder.
Note:
have enough available space.
3. (Optional) Tap New Folder to add a sub-folder. Enter a name for the folder and then tap Done.
4. In the Export Type section select the appropriate format:
Select Clips if the image is a multi-frame clip.
o
Select Frame if the selected image is a single-frame image.
o
5. (Optional) Type a new file name.
In the field located above the Export Type options, the system displays the system-defined date and
time stamp file name. You can change the file name for any export.
Note:
enter a new file name other than the default. When exporting multiple clips
or frames, the text entered will be the start of each of the exported files.
6. Tap Export. The system exports the images to the destination folder a nd then displays an export
report.
Note: The Study browser inventory table is the only option that is not available
when exporting from the Mode window.
Study Browser
The Export button will be disabled if the destination selected does not
To identify and group these files more easily in your export folder,
Vevo F2 Imaging System User Manual
338
