4. Tap Paste Regions.
5. The copied PA Region measurement is placed on the image, with its original coordinates.
To Copy and Paste all PA Region Measurements
1. Tap Copy Regions from the Measurements panel.
2. Acquire a new image, load an image into review or use the currently loaded image.
3. Tap Paste Regions.
4. The copied PA Region measurements are placed on the image, with their original coordinates.
Creating PA Region Graphs
Use the PA Region Graph t o measure and graph the changes in PA-Mode data across time or frames in a
defined region. Define the region of interest, then generate a graph that measures the signal changes that
appear in that region over your PA-Mode cine loop.
Quantification is available for the average threshold signal power of each P A Region measurement.
Displayed by the label 'PA Avr Thresh', quantification values represent the average maximum intensity and
applies only to the frame on which it appears (expect this value to change from frame to frame within a cine
loop). This quantification is available for PA-Mode (Single), PA-Mode (Multi-wavelength), and PA-Mode
(Spectro).
Quantification is also available for the average signal power and the average threshold signal power for
Multiplexed PA Region measurements. Displayed by the label 'PA Avr' and 'PA Avr Thresh' preceded by the
Layer name, quantification values calculate the average based on calculations described on the multiplexer
panel. This quantification is available for PA-Mode (Multi-wavelength), PA-Mode (Unmix), and PA-Mode
(Spectro).
A PA Region graph can be populated from any PA Region measurement.
To Create a PA Region Graph
1. Select the PA Region from the Measurements panel, then tap the Graph icon for that measurement.
2. The PA Region Analysis screen appears.
