Note:
Mode box will maximize to fit the entire image. Making the PA-Mode box
smaller will disable this feature. Manually maximizing the PA-Mode box will
re-enable this feature.
Laser Tab
Tap this control to calibrate, initialize and configure the laser. The laser should be calibrated to ensure
optimal image quality.
Note: For more information about laser calibration, refer to Laser Calibration on
page 190.
PA-Mode Image Acquisition Workflow
Acquiring an image in PA-Mode involves the following workflow:
1. Start an imaging session, then tap PA-Mode.
The system enters staging mode and shows B-Mode data. The PA-Mode box and the Guide Area
from the PA Guide appears.
Note: For more information about the PA Guide, refer to PA Guide on
page 183.
2. Select the desired laser port (refer to LAZR Port on page 179).
3. (Optional) To enable the PA Guide Line, tap PA Guide and select Guide Line.
Modes
By default, if the B-Mode image dimensions are changed, the PA-
Vevo F2 Imaging System User Manual
165
